ENGINE

Type                           686cc, Liquid-cooled, 4-stroke, 1-cylinder

Bore x Stroke             102mm x 84mm

Compression              Ratio 9.2:1

max.power                  25 kw (33.5hp)/5000-5500rpm

max.torque                 49 N.m/5000rpm

Carburetion                PD42J-A

Ignition                       CDI

Starting                      Electric

Transmission             L-H-N-R

Drive Train                 Axle



CHASSIS

Suspension/Front      Independent double swing arm

Suspension/Rear       Independent double swing arm

Brakes/Front              Dual ventilated hydraulic disc

Brakes/Rear               Dual ventilated hydraulic disc

Tires/Front                  AT25 x 8-12 radial

Tires/Rear                   AT25 x 10-12 radial



DIMENSIONS

L x W x H                    3950mm x 1430mm x 1900mm

Packing Size               2300mm x 1400mm x 1240mm

Seat Height                 31-1/8" (790mm)

Wheelbase                  113" (2870mm)

Ground Clearance       9-5/8" (245mm)

Fuel Capacity               7.93 Gallons (30L)

Dry Weight                   1487 lbs (669kg)
