Engine

Type 686cc, Water cooled, 5-valve, 4-stroke, 1-cylinder

Bore x Stroke Dim 4” x 3.3”

Compression Ratio 9.2：1

Max Power 33.5 hp/5500rpm

Max Torque 30.17 ft-lb/4000rpm

Max Speed 40.4 mph

Gas Supply Type Electric Fuel Injection

Starting Mode Electric

Transmission L-H-N-R-P

Drive System Shaft



Chassis

Suspension Front Independent double swing arm

Suspension Rear Independent double swing arm

Brake Front Dual ventilated hydraulic disk brake system

Brake Rear Ventilated hydraulic disk

Tire Front AT25×8-12 radial

Tire Rear AT25×10-12 radial

Winch Standard

Alloy Wheels Optional



Dimensions

Dimensions (LxWxH) 118.5”x57.5”x72.5”

Seat Height (inch) 31.3"

Wheelbase (inch) 74.5"

Ground Clearance 9.7"

Fuel Tank Capacity 7.7 Gal

Gross/Net Weight (lbs) 1382/1155

Front LIght 12V35W/35W x 2, 12V5W x 2

Rear Light 12V5W/21W x 1

Loading QTY (20LFT/40F) 4/9

Battery 12V/32Ah
