ENGINE

800cc, Liquid cooled, Twin V-Type Cylinder, 8 Valve

Bore x Stroke(inch):       91 x 61.5 mm

Max. Power :                  55 hp @ 6800 rpm

Max Torque:                   67.12 ft lbf @ 4250 rpm

Gas Supply Type:           Electric Fuel Injection

Start Type:                      Electric

Transmission:                 CVT, L-H-N-R-P

Drive system:                  2WD, 4WD, F & R Differential Lock



CHASSIS

Suspension Front:          Independent dual cross arm with hydraulic spring combined type

Suspension Rear:           Independent dual cross arm with hydraulic spring combined type

Tire Front:                        AT25×8-12 radial

Tire Rear:                         AT25×10-12 radial



Dimensions

LxWxH(inch):                  105.1″x53″x74.8″

Wheelbase(inch):            74.6″

Ground Clearance(inch): 12.6″

Battery:                            12V/32Ah

Gross/Net Weight(lbs):    1,565 / 1,124
